CU/XLPE/WBT/CWS/WBT/PE 6.35/11 kV
CONSTRUCTION
Stranded aluminium conductor,Inner semi conductive layer,XLPE insulation,Outer semi conductive layer,Semi conductive tape,Copper screen,Swellable tape,PE outer jacket
TECHNICAL INFORMATION
RoHS Compliance
Max. Operating Temprature: 90 °C
Max. Short CircuitTemprature: 250 °C
Installation Temprature: -20 °C
Underground
Damp and Wet Places
In Conduit
In Cable Ducts
Industrial Plants
APPLICATION
These are cables with low dielectric losses used in energynetworks with sudden load changes. Laid in residential orindustrial areas, underground or in ducts. If the cable getswater inside due to the mechanical demages, swellable tapesprevent the movement of the water inside the cable.
